Specifications
NetEvoTech EvoMo R1 Series
General
Models
R1 (radio version) / R1 S (network version)
Dimensions
103 × 104 × 55 cm
Weight
108 kg
Power source
All-electric
Cutting Performance
Cutting width
79 cm
Cutting height
20–100 mm
Cutting system
Dual-motor cutting system
Cutting motor power
2 × 850 W
Blade speed
3,000 rpm
Mowing efficiency
2,000 m²/h*
Drive System
Drive system
Four-wheel electric drive
Drive motor power
4 × 400 W servo motors
Steering system
Differential steering with in-place turning
Travel speed
0–6 km/h
Maximum slope
20°*
Battery & Charging
Battery type
Rechargeable LiFePO₄ battery
Battery capacity
48 Ah
Removable battery
Yes
Runtime per charge
Up to 2 hours*
Charging time
Approximately 2.5 hours*
Navigation & Control
Positioning system
GNSS-RTK
Remote controller
H12 Pro
Remote control range
Up to 1 km with a clear line of sight*
Operating modes
Autonomous mowing and remote-controlled mowing on both models
R1 — Radio Version
Autonomous connection
Radio link; no SIM cards required
Obstacle response
Radar detects obstacles and stops the mower
Automatic obstacle avoidance
Not supported
Charging station
Not included
Automatic docking and charging
Not available
R1 S — Network Version
Autonomous connection
Mobile network; suitable network coverage required
SIM cards
Two SIM cards: one in the mower and one in the ground base station
Obstacle response
Radar supports obstacle stopping and automatic obstacle avoidance
App operation
Supported via the designated Android app
Charging station
Included
Automatic docking and charging
After mapping and starting work, recall the mower to its starting point. It automatically reverses into the charging station and begins charging.
* Mowing efficiency and runtime vary with grass conditions, terrain and operating settings. Charging time varies with battery condition and charging conditions. Slope suitability depends on ground conditions and traction. Remote control range requires a clear line of sight and varies with the operating environment.
Autonomous operation requires suitable GNSS-RTK positioning conditions. The R1 requires a suitable radio link; the R1 S requires two SIM cards and suitable mobile network coverage.
Both models support remote-controlled operation using the H12 Pro controller without SIM cards. A charging station is included with the R1 S only.
